OpenShift with Kuryr on top of OpenStack

Introduction to Kuryr CNI

Kuryr is a CNI plugin using Neutron and Octavia to provide networking for pods and services. It is primarily designed for OpenShift clusters running on OpenStack virtual machines. Kuryr improves the network performance.

Kuryr is recommended for OpenShift deployments on encapsulated OpenStack tenant networks in order to avoid double encapsulation: running an encapsulated OpenShift SDN over an encapsulated OpenStack network i.e whenever VXLAN/GRE/GENEVE are required. Conversely, implementing Kuryr does not make sense when provider networks, tenant VLANs, or a 3rd party commercial SDN such as Cisco ACI or Juniper Contrail are implemented.

Kuryr Architecture

Kuryr components are deployed as pods in the kuryr namespace. The kuryr-controller is a single container service pod installed on a node as a deployment OpenShift resource type. The kuryr-cni container installs and configures the Kuryr CNI driver on each of the OpenShift masters and compute node as a daemonset. The Kuryr controller watches the OpenShift API server for pod, service and namespace create, update and delete events. It maps the OpenShift API calls to corresponding objects in Neutron and Octavia. This means that every network solution that implements the Neutron trunk port functionality can be used to back OpenShift via Kuryr. This includes open source solutions such as OVS and OVN as well as Neutron-compatible commercial SDNs. That is also the reason the OpenvSwitch firewall driver is a prerequisite instead of the ovs-hybrid firewall driver when using OVS.

For more deatils please refer to kuryr-kubernetes github page.

Installing Red Hat Openstack Platform 16.2 with Octavia

For testing purpose we will be deploying All-in-One OSP deployment using tripleo. For steps please refer to this project.

Deploying Red Hat Openshift Container Platform 4.8

We will use IPI method to deploy OCP on top of OSP. Prerequisite for installing OCP on OSP are

• Red Hat OSP 16.2 installed with octavia
• A project in which OCP instances will be created
• Project should meet the minimum quota
• A user who has access to project and also have swiftoperator role in the project

Creating environment in OSP

1. Creating project in Openstack

   [stack@aio ~]$ openstack project create --description 'Openshift 4.8' ocp48 --domain default
   [stack@aio ~]$ openstack project list
   [stack@aio ~]$ openstack project list
   +----------------------------------+---------+
   | ID                               | Name    |
   +----------------------------------+---------+
   | 2b1201670e264cb98a68f8f52a07c581 | service |
   | 618498a4b6e54bc7b4fbc45ffefe3852 | admin   |
   | 636beab46fdf4e7da8b150b9c3d9c01f | ocp48   |
   +----------------------------------+---------+

2. Create a user and make it a member of the project and assign swiftoperator role to it.

   [stack@aio ~]$ openstack user create --project ocp48 --password PASSWORD ocpadmin
   +------------+----------------------------------+
   | Field      | Value                            |
   +------------+----------------------------------+
   | email      | None                             |
   | enabled    | True                             |
   | id         | 6322872d9c7e445dbbb49c1f9ca28adc |
   | name       | new-user                         |
   | project_id | 636beab46fdf4e7da8b150b9c3d9c01f |
   | username   | ocpadmin                         |
   +------------+----------------------------------+
   [stack@aio ~]$ openstack role add --user ocpadmin --project ocp48 swiftoperator

3. Modify the quota for project ocp48

   [stack@aio ~]$ sudo openstack quota set --secgroups 250 --secgroup-rules 1000 --ports 1500 --subnets 250 --networks 250 ocp48

4. Create two floating ip and add records in DNS

   [stack@aio ~]$ openstack floating ip create --description "API" ext-net
   [stack@aio ~]$ openstack floating ip create --description "Ingress" ext-net

   Deploying Openshift Cluster

   Create the install-config for the cluster

   $ ./openshift-install create cluster --dir=pluto --log-level=debug

   Update the install-config.yaml

apiVersion: v1
baseDomain: home.lab
compute:
- architecture: amd64
  hyperthreading: Enabled
  name: worker
  platform: {}
  replicas: 3
controlPlane:
  architecture: amd64
  hyperthreading: Enabled
  name: master
  platform: {}
  replicas: 3
metadata:
  creationTimestamp: null
  name: pluto
networking:
  clusterNetwork:
  - cidr: 10.128.0.0/14
    hostPrefix: 23
  machineNetwork:
  - cidr: 10.0.0.0/16
  networkType: Kuryr
  serviceNetwork:
  - 172.30.0.0/16
platform:
  openstack:
    lbFloatingIP: 192.168.50.237           <== API FIP
    ingressFloatingIP: 192.168.50.212      <== APP FIP
    cloud: standalone
    defaultMachinePlatform:
      type: ocp.small
    externalDNS: [192.168.50.1,192.168.1.1]
    externalNetwork: ext-net
    trunkSupport: true
    octaviaSupport: true
publish: External
pullSecret: '<pull secret from cloud.redhat.com>'
sshKey: |
  <your ssh public key>

Deploy cluster

$ ./openshift-install create cluster --dir pluto --log-level debug
......
time="2021-09-21T15:54:16-04:00" level=debug msg="Cluster is initialized"
time="2021-09-21T15:54:16-04:00" level=info msg="Waiting up to 10m0s for the openshift-console route to be created..."
time="2021-09-21T15:54:16-04:00" level=debug msg="Route found in openshift-console namespace: console"
time="2021-09-21T15:54:16-04:00" level=debug msg="OpenShift console route is admitted"
time="2021-09-21T15:54:16-04:00" level=info msg="Install complete!"
time="2021-09-21T15:54:16-04:00" level=info msg="To access the cluster as the system:admin user when using 'oc', run 'export KUBECONFIG=/Users/aaggarwa/Work/Lab/ocp-clusters/osp/ocp4.8/pluto/auth/kubeconfig'"
time="2021-09-21T15:54:16-04:00" level=info msg="Access the OpenShift web-console here: https://console-openshift-console.apps.pluto.home.lab"
time="2021-09-21T15:54:16-04:00" level=info msg="Login to the console with user: "kubeadmin", and password: "QSKqk-6qNTa-RQz4Y-B3juj""
time="2021-09-21T15:54:16-04:00" level=info msg="Time elapsed: 0s"

Once the cluster is deployed successfully. Login to OSP dashboard and notice that each pod has its own network

Load balancers for each namespace

Now let us deploy a sample app

$oc new-project test-project
$oc new-app --git https://github.com/openshift/nodejs-ex.git

Conclusion

Using Kuryr with OpenShift on OpenStack 16 provides the benefits of using OpenStack’s Neutron networking directly for OpenShift pods and services, instead of the OpenShift SDN. Avoiding double encapsulation improves performance and reduces troubleshooting complexity, and you also get the benefits of directly associating floating IPs to OpenShift services, which is useful in several applications.
